Aprašymas
High Brightness Innovative multipurpose BSW moving head with the newest technology NEOLUX lamp 295 watt, Color Temperature: 8000K, high precision 138mm glass optic system with zoom 2.7? – 36? projection angle, 7 rotating gobos plus open, 16 static gobos plus open, 11 colors plus open CTO + CTB, 2 morphing prism 4 and 8 facet, Powercon IN/OUT, 20kg.
Product Description
Beam/Spot/Wash fixture, based on Stage 295 Watt Discharge Lamp.
The newest technology NEOLUX lamp 295 watt become Nitro BSW the ideal sollution
for large events and concerts that demands a work horse luminaire.
Light Source / Optics
Based on Stage 295 Watt discharge lamp, 8000 Kelvin, life span of 1500 hours, and maximum luminus flux of 14000 lm.
Linear zoom and focus.
Beam mode offers 3° to 27°, spot mode ranges from 7° to 36° beam angles.
Frost filter for wash light simulation projection.
Effects
11 dichroic colours, plus open (UV, CTO & CTB included).
16 fixed gobos, plus open.
7 rotating gobos, plus open (includes dichroic colored gobos).
1x double rotating prism (4 + 8 Facet).
Linear zoom
Motorized focus from 2,5 to 15 meters.
Frost filter.
Double blade shutter for dimming and strobe effects.
Control
Auto, Music & DMX control options.
DMX control with 15, 17 & 19 control channels.
2,4″ TFT Screen for options menu navigation.
Lamp hour counter.
Pan control range: 630° / 540° / 360°
Tilt control range: 270° / 180°/ 90°.
Technical Specifications
Power Supply: AC90/260 Volt, 50/60 Hz.
Power Consumption: 390 Watt.
Environmental temperature allowance: -35°C to +45°C.
Fan cooled.
55dB noise level.
IP20, for indoor use only.
Fixture dimensions: 379 x 255 x 585 mm
Packing dimensions: 510 x 470 x 650 mm
Net Weight: 20 Kgs,
Gross Weight: 22 Kgs.
